TPYB1400
This machine performs integrated preshrinking and ironing treatments on cotton, blended, and synthetic fiber-based tubular knitted fabrics.
What can TPYB1400 do for you
Incorporates magnetic levitation-driven split shuttle support plates, achieving fabric width control accuracy of ±5mm with gloss-free surface finish, while the dual-motor overfeed system eliminates weft distortion during cloth feeding.
A hole detection sensor is installed at the fabric feeding end, triggering automatic machine shutdown upon detecting edge tears or defects.
Electrically heated thermal oil roller with uniform temperature distribution, automatic control, freely adjustable settings, and a maximum operating temperature of 220°C.
Variable Frequency Speed Regulation.
20mm thickened blanket combined with PTFE (Teflon) film achieves damping-based shrinkage control, enabling warp-wise shrinkage rates as low as 3%.
Stainless steel dual-nozzle steam chamber with high moisture output and uniform distribution.
Equipped with a support plate detachment detection safety switch to halt operation automatically.
The system can be configured with a PLC + touchscreen control system and an online width detection system based on user requirements.
Technical specifications of TPYB1400
Working width
1400mm
Motor power
16.5KW
Electrical heating motor
54Kw/2 roller 27KW/1 roller
Heating way
Electrical heating, thermal oil, steam heating
Machine speed
0-30m/min
Roller Diameter
500mm
overfeeed reate
0-30%
Temperature of chamber
100-180℃
Pre-shrinking rate
5%
Shape size
5910 × 2650 × 2400mm
Weight
5T
Production
10T/DAY
